Chromium Nitride (CrN) PVD Coating
Category: PVD Coating
Description
CrN (chromium nitride) is an excellent coating that provides lubricity and superior wear and corrosion resistance. CrN has a very low residual stress, which provides for the best adhesion and ductility of any of the PVD coatings. High hardness, low coefficient of friction and the low residual stress of Calico CrN combine to resist abrasive, metal-on-metal wear, and galling. CrN is an excellent coating for applications such as automotive parts, molds and dies, pump parts, shafts, dry deep drawing and works especially well when used against copper.
Substrate(s)
- Hardened Steel
- Steel
Thickness
- Thickness (µ): 1 - 4
Color(s)
- Metallic Silver
Process
CrN is applied using lateral rotating cathode technology in a PVD (physical vapor deposition) process. Material is vaporized from a solid source in the form of atoms/molecules and then transported in the form of a vapor through a vacuum, low pressure gas/plasma to the substrate where it condenses. The standard process temperature is 425°C/750°F and provides the toughest coating. Low deposition temperature possible (220°C/420°F).
Advantages
High hardness, Low residual stress, Good abrasive wear resistance, High reliability in dry operations, Lubricants can be reduced or replaced, Good corrosion resistance, Performs under conditions of high load, Excellent chemical resistance.
- Chemical Resistant
- Heat Resistant
- High Wear Resistant
- Increased Hardness
- Increased Lubricity
- Low Coefficient of Friction
- Oxidation Resistant
